Digital Design : BIMCO

Module Overview

Building Information Modelling (BIM) is an intelligent 3D model-based process that allows collaboration among building professionals so that they can efficiently plan, design, construct, and manage buildings and infrastructure. This subject equips me with practical BIM modelling skills for creating virtual models of mechanical, electrical, and plumbing systems. In addition, essential knowledge about these systems, such as their working principles, system diagrams interpretation, and the energy optimization techniques will also be covered.

Level 6 Floor plan

Air Conditioning

The VAVs are placed where each diffuser, return and supply are grouped up with a VAV box​

A VAV box is placed in each one of the 3 corners as well as in the middle of the building​

Fire Protection

Upright sprinklers are placed in the mechanical room and the toilets ​

Non-hosted sprinklers are placed in the mechanical room​

Hosted sprinklers are placed everywhere else​

Each sprinkler is placed in each room and the piping for the ​main pipe is 40 mm​ and horizontal pipe from the riser area to the main zone is 60mm​

Plumbing

All fixtures used :

M_Water Closet_Flush Valve – Wall Mounted ​

M_Lavatory – Wall Mounted ​

M_Urinal with Wing – Wall Mounted​

Lighting

All lighting used :

M_Plain Recessed Lighting Fixture: 600x1200 – 230V​

M_Plain Recessed Lighting Fixture: 600x600 – 230V​

M_Downlight – Recessed Can- Fluorescent – 230V​

M_Sconce Light – Flat Round – 100W - 230V
